We could quite easily re-arrange the additional AND gates in the above counter circuit to produce other count numbers such as a Mod-12 counter which counts 12 states from”0000″ to “1011” (0 to 11) and then repeats making them suitable for clocks, etc.
Thus, the count is reset and starts over again at “0000” producing a synchronous decade counter. Flip-flop FF0 toggles on every clock pulse. The additional AND gates detect when the counting sequence reaches “1001”, (Binary 10) and causes flip-flop FF3 to toggle on the next clock pulse. If we enable each JK flip-flop to toggle based on whether or not all preceding flip-flop outputs ( Q) are “HIGH” we can obtain the same counting sequence as with the asynchronous circuit but without the ripple effect, since each flip-flop in this circuit will be clocked at exactly the same time. These additional AND gates generate the required logic for the JK inputs of the next stage. The J and K inputs of flip-flop FFB are connected directly to the output Q A of flip-flop FFA, but the J and K inputs of flip-flops FFC and FFD are driven from separate AND gates which are also supplied with signals from the input and output of the previous stage. Then the synchronous counter follows a predetermined sequence of states in response to the common clock signal, advancing one state for each pulse. It can be seen above, that the external clock pulses (pulses to be counted) are fed directly to each of the J-K flip-flops in the counter chain and that both the J and K inputs are all tied together in toggle mode, but only in the first flip-flop, flip-flop FFA (LSB) are they connected HIGH, logic “1” allowing the flip-flop to toggle on every clock pulse.
